XY-1A 180m Water Well Horizontal Directional Drilling Rigs

Model Number : XY-1A

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiation

Delivery Time : 10-20 days working days

Payment Terms : T/T, L/C, T/T, Western Union

Brand Name : OEM

Certification : ISO,CE

Type : horizontal and directional drilling

Voltage : 220V

Usage : geological core drilling

Power Type : Diesel or Electric

Drilling depth : 30--180m

Drill rod caliber : 50 42mm

Drilling angle : 90°~75°

Packaging Details : Wooden cases standard export package

Supply Ability : Based on the detailed quotation

Contact Now

Water Well Horizontal Drilling Machine , XY-1A Crawler Mounted Drill Rig

Product Description

The XY-1A drilling rig is a kind of widely used and hydraulic feeding drill, which has the characteristics of big power, great lifting force (2T) and high transmission torque.

1 Engineering geological investigation of railways, hydropower, traffic, bridges, dam foundations and other buildings.

2 Geological core drilling, physical prospecting.

3 Small grout Confucius, drill hole drilling.

4 Small well drilling.

Technology Parameter

Unity machine parameter
Drilling depth	30--180m
Drill rod caliber	50 42mm
End hole caliber	75 46mm
Max. open hloe caliber	220mm
Drilling angle	90°~75°
Drill weight (No include power)	610kg
Unity machine dimensions	2.1×0.9×1.3m
Spindle
spindle speed	130, 300, 480, 730, 830, 1045r/min
Spindle stroke	450mm
Hoist
Max.single line hoisting capacity	1600kg
Single line lifting speed	1.06, 0.67, 0.32m/s
Wirerope caliber	13mm
Wirerope cubic measure	35m
Hug floodgate caliber	254mm
Hug folldgate belt width	50mm
Distance between drill and hole	230mm
Mud pump
Type	Horizontal single urn twin-action
Displacement	170L/min
Maximum pressure	1.5Mpa
Work pressure	0.7Mpa
Power
Diesle engine	S1105 18HP
Electric motor	Y160M—4 15KW
